1PC/4PCS Hobbywing XRotor 3110 900KV 1150KV / 3115 900KV 1050KV 4-6S M5 Shaft Brushless Motor for 8 Inch/9 Inch/10 Inch FPV Drone
1 in stock
- SKU : 2028095
- Condition : New
- Brand : Hobbywing
- Processing Time : Ships Within 24-48 Hours
- Return Policy : 30-day refund or replacement
Price range: $23.99 through $99.99
Feature:
1. High-performance0.2mm siliconsteel sheets.
2. The multi-strand enameled wire winding design increases the slot full rate by approximately more than 5%.
3. 200°℃high-temperature resistant enameled wire.
4. Meet the needs of users pursuing extreme motor performance.
5. Uses N52 strong magnetic tileswith an arc- shaped desiqn to provide a stronger torque to the motor.
Specification:
Brand: Hobbywing
Model: Xrotor 3110 900KV/1150KV 3115 900KV/1050KV Brushless Motor(Optional)
|
Model |
Xrotor 3110 900KV |
Xrotor 3110 1150KV |
Xrotor 3115 900KV |
Xrotor 3115 1050KV |
|
Product Number: |
30418005 |
30418006 |
30418007 |
30418008 |
|
KV Rating: |
900KV |
1150KV |
900KV |
1050KV |
|
LiPo Cells (LiPo): |
4-6S |
4-6S |
4-6S |
4-6S |
|
No-Load Current: |
2.2A/24V |
2.8A/24V |
2.0A/24V |
2.8A/24V |
|
Maximum Continuous Current: |
63A/10s |
69A/6s |
81A/10s |
70A/30s |
|
Maximum Continuous Rating: |
1500W/10s |
1656W/6s |
1940W/9s |
1675W/30s |
|
Maximum Thrust: |
362g |
412g |
517g |
442g |
|
Motor Weight: |
89g |
89g |
125g |
126g |
|
Motor Size: |
Φ37.2*27mm |
Φ37.2*27mm |
Φ37.2*32mm |
Φ37.2*32mm |
|
Slot/Pole: |
12N14P |
12N14P |
12N14P |
12N14P |
|
Wire Size: |
18AWG |
18AWG |
16AWG |
16AWG |
|
Wire Length: |
250mm |
250mm |
