CADDXFPV Alink ELRS 2.4GHz 10CH 100mW Full-Bearing Hall-Sensor Gimbal Radio Transmitter Mode 2 for CADDX PROTOS FPV Drones

CADDXFPV Alink ELRS 2.4GHz 10CH 100mW Full-Bearing Hall-Sensor Gimbal Radio Transmitter Mode 2 for CADDX PROTOS FPV Drones

This product is equipped with a built-in ELRS 2.4GHz RF module and a 10-channel RC model remote controller. It can be used to control any RC model equipped with an ELRS 2.4GHz receiver.
FPV Flight Simulator
This product can be directly connected to a computer using a Type-C data cable. The Type-C port is located at the center of the back of the remote controller. Once connected, you can use an FPV simulator for practice.

Specification:
Item Name: CADDXFPV Alink
Model: C0PJ-YKL19
FCC IC: 2BHG9-C0PJ-YKL19
Main Control Chip: AT32 F413RCT7
RF Module: ELRS 2.4GHZ
RF Protocol: CRSF
Max RF Power: 100mW (20dB)
Number of Available Channels: 10 Channels (including 4 joystick channels)
Joystick Type: Full-Bearing Hall-Sensor Joystick Assembly
Function Switch: 1 x Latching Button / 2 x Momentary Buttons /2 x 3-Position Toggle Switches / 1 x Scroll Wheel
Status Indicator Module: 4 x Status Indicator LEDs / Buzzer
Charging & Communication Interface: USB-Type C
Battery Specification: Lipo 1s 1000mAh
Max Charging Power: 5V / 1A / 3.50W
Charging Time: ≈90:00 min
Operating Voltage Range: DC 3.50V~4.20V
Dx108mmx58mm
Weight: 180g±5g

Package included:
1 x CADDXFPV Alink Radio Controller
